SPECIFICATION
DESIGN |
Single speaker system with stereo L/R inputs, 3-driver, 2 x 2-way acoustic suspension, weather,water, UV-resistant PolyGlass™ enclosure |
CROSSOVER |
Two 3rd-order electro-acoustic at 2.3 kHz |
HIGH FREQUENCY DRIVER |
Two 25-mm (1 in) PTD™ domes |
FREQUENCY RESPONSE ON-AXIS |
±2 dB from 80 Hz - 20 kHz |
FREQUENCY RESPONSE 30° OFF-AXIS |
±2 dB from 80 Hz - 15 kHz |
MID/BASS FREQUENCY DRIVER |
Dual voice-coil, 165-mm (6-1/2 in) ICP™ cone, die-cast chassis |
SENSITIVITY ROOM / ANECHOIC |
91 dB / |
LOW FREQUENCY EXTENSION |
55 Hz (DIN) |
SUITABLE AMPLIFIER POWER RANGE |
15 - 100 watts Mono; 15 - 50 watts / channel Stereo Input |
MAXIMUM INPUT POWER |
70 watts Mono; 35 watts / channel Stereo Input |
IMPEDANCE |
Compatible with 4 ohms Mono; 8 ohms / channel Stereo Input |
DIMENSIONS HXWXD |
10.75" × 7.625" × 7.375" (27.3cm × 19.4cm × 18.7cm) |
WEIGHT |
8.3 lbs. (3.8 kg) |
