SPECIFICATIONS
-
Nominal Impedance: 8 Ohms
-
Sensitivity: 89dB (2.83V/ 1m)
-
Frequency Response: 52Hz - 20kHz (+/-6dB) open-backed
-
Crossover Frequencies: 2.8kHz
-
Drive Units: LF: 160mm (6.5in.), HF: 16mm (0.6in.)
-
Recommended Amplifier Power: 10-100W
-
Product External Dimensions: Diameter: 234.6mm (9.24in.), Depth: 88.7mm (3.49in.)
-
Cut-Out Dimensions: Diameter: 196mm (7.71in.)
-
Mounting Thickness: Ceiling Thickness (Maximum): 36mm (1.42 in.), Ceiling Thickness (Minimum): 6mm (0.24 in.)
-
Mounting Depth from Surface: 85.2mm (3.35in.)
-
Optional Rough in Frame: RIF160R
-
Optional Rear Enclosure: RNC160R
-
Net Weight: 1.4kg (3.1lbs)
